Latest TMOS Administration 201 Practice

NEW QUESTION 1
In the BIG-IP Configuration Utility, a user requests a single screen view to determine the status of all Virtual Servers and associated pool members, as well as any iRules in use. Where should the BIG-IP Administrator instruct the user to find this view?

• A. Local Traffic > Monitors
• B. Local Traffic > Virtual Servers
• C. Local Traffic > Network Map
• D. Statistics

Answer: C

Explanation:
Network Map can display vs and its associated pool, pool member, and irule, can be retrieved, and can be quickly linked.

NEW QUESTION 2
A BIG-IP Administrator is configuring a pool with members who have differing capabilities. Connections to pool members must be load balanced appropriately.
Which load balancing method should the BIG-IP Administrator use?

• A. Least Sessions
• B. Least Connections (member)
• C. Fastest (node)
• D. Weighted Least Connections (member)

Answer: D

NEW QUESTION 3
A BIG-IP Administrator needs to apply a license to the BIG-IP system to increase the user count from the base license.
Which steps should the BIG-IP Administrator?

• A. System License > Re-activate> Add-On Registration> Edit
• B. System > License > Re-activate > Base Registration> Edit
• C. Device Management > Devices > Select BIG-IP System > Update
• D. System > Configuration >Device > General

Answer: A

NEW QUESTION 4
As a part of the Setup Utility, the administrator sets the host name for the BIG IP. What would be the result if the two systems in a redundant pair were set to the same host name?

• A. Host names do not matter in redundant pair communication.
• B. In a redundant pair, the two systems will always have the same host nam
• C. The parameter is synchronized between the systems.
• D. The first time the systems are synchronized the receiving system will be assigned the same self-IP addresses as the source system.
• E. When the administrator attempts to access the configuration utility using the host name, they will always connect to the active system.

Answer: C

NEW QUESTION 5
Which three properties can be assigned to nodes? (Choose three.)

• A. ratio values
• B. priority values
• C. health monitors
• D. connection limits
• E. loadbalancing mode

Answer: ACD

NEW QUESTION 6
During a maintenance window, an EUD test was executed and the output displayed on the screen. The BIG-IP Administrator did NOT save the screen output. The BIG-IP device is currently handling business critical traffic. The BIG-IP Administrator needs to minimize impact. What should the BIG-IP Administrator do to provide the EUD results to F5 Support?

• A. Boot the device into EUD then collect output from console
• B. Execute EUD from tmsh and collect output from console
• C. Collect file /var/log/messages
• D. Collect file /shared/log/eud.log

Answer: D

NEW QUESTION 7
A BIG-IP Administrator reviews the Plane CPU Usage performance chart and discovers a high percentage of Control Plane utilization.
Which type of traffic does this indicate a higher usage of?

• A. Administrative
• B. Tunnel
• C. Accelerated ,
• D. Application

Answer: A

NEW QUESTION 8
Which IP address will the client address be changed to when SNAT automap is specified within a Virtual Server configuration?

• A. The floating self-IP address on the VLAN where the packet leaves the system.
• B. The floating self-IP address on the VLAN where the packet arrives on the system.
• C. It will alternate between the floating and non floating self-IP address on the VLAN where the packet leaves the system so that port exhaustion is avoided.
• D. It will alternate between the floating and non floating self-IP address on the VLAN where the packet arrives on the system so that port exhaustion is avoided.

Answer: A

NEW QUESTION 9
A BIG-IP Administrator is unable to connect to the management interface via HTTPS. What is a possible reason for this issue?

• A. The port lockdown setting is configured to Allow None.
• B. An incorrect management route is specified.
• C. The IP address of the device used to access the management interface is NOT included in the "P Allow" list in the Configuration Utility.
• D. The IP address of the device used to access the management interface is NOT included in the "httpd Allow" list in the CLI.

Answer: D

NEW QUESTION 10
Which statement is true about the synchronization process, as performed by the Configuration Utility or by typing b config sync all?

• A. The process should always be run from the standby system.
• B. The process should always be run from the system with the latest configuration.
• C. The two /config/bigip.conf configuration files are synchronized (made identical) each time the process is run.
• D. Multiple files, including /config/bigip.conf and /config/bigip_base.conf, are synchronized (made identical) each time the process is run.

Answer: C

NEW QUESTION 11
A virtual server is listening at 10.10.1.100:80 and has the following iRule associated with it:
when HTTP_REQUEST { if { [HTTP::header UserAgent] contains "MSIE" }
{ pool MSIE_pool }
else { pool Mozilla_pool }
If a user connects to http://10.10.1.100/foo.html and their browser does not specify a UserAgent, which pool will receive the request?

• A. MSIE_pool
• B. Mozilla_pool
• C. Non
• D. The request will be dropped.
• E. Unknow
• F. The pool cannot be determined from the information provided.

Answer: B

NEW QUESTION 12
Which two statements are true about NATs? (Choose two.)

• A. NATs support UDP, TCP, and ICMP traffic.
• B. NATs can be configured with mirroring enabled or disabled.
• C. NATs provide a one-to-one mapping between IP addresses.
• D. NATs provide a many-to-one mapping between IP addresses.

Answer: AC

NEW QUESTION 13
Where is the loadbalancing mode specified?

• A. within the pool definition
• B. within the node definition
• C. within the virtual server definition
• D. within the pool member definition

Answer: A

NEW QUESTION 14
DNS queries from two internal DNS servers are being load balanced to external DNS Servers via a Virtual Server on a BIG-P device. The DNS queries originate from 192.168.101.100 and 192.168.101.200 and target 192.168.21.50
All DNS queries destined for the external DNS Servers fail
Which property change should the BIG-IP Administrator make in the Virtual Server to resolve this issue?

• A. Protocol Profile (Client) to DNS-OPTIMZED
• B. Type to Performance (HTTP)
• C. Protocol to UDP
• D. Source Address to 192.168.101.0/24

Answer: C

NEW QUESTION 15
A BIG-IP Administrator notices that one of the servers that runs an application is NOT receiving any traffic. The BIG-IP Administrator examines the configuration status of the application and observes the displayed monitor configuration and affected Pool Member status.

What is the possible cause of this issue?

• A. The Node Health Monitor is NOT responding.
• B. The application is NOT responding with the expected Receive String.
• C. HTTP 1.1 is NOT appropriate for monitoring purposes.
• D. The BIG-IP device is NOT able to reach the Pool.

Answer: A

NEW QUESTION 16
Which two can be a part of a virtual server's definition? (Choose two.)

• A. rule(s)
• B. pool(s)
• C. monitor(s)
• D. node address(es)
• E. loadbalancing method(s)

Answer: AB

NEW QUESTION 17
Monitors can be assigned to which three resources? (Choose three.)

• A. NATs
• B. pools
• C. iRules
• D. nodes
• E. SNATs
• F. pool members
• G. virtual servers

Answer: BDF
